Differential Pressure Transmitters

Product Description

Product Details :

Features :

• Automatic static pressure & temperature compensation
• Response times as fast as 100ms
• Easy to use and intuitive display capabilities
• Intuitive External Zero, Span and configuration
• capability
• On-board diagnostic capabilities
• Integral Dual Seal design for highest safety based on ANSI/NFPA 70-202 and ANSI/ISA 12.27.0
• World class overpressure protection
• Full compliance to SIL 2/3 requirements.

Standard LCD Display Features:

• Modular (may be added or removed in the field)
• Supports HART protocol variant
• 0, 90,180, & 270 degree position adjustments
• Configurable (HART only) and standard (Pa, KPa, MPa, KGcm2, Torr, ATM, inH2O, mH2O, bar, mbar, inH2O, inHG, FTH2O, mmH2O, mm HG, & psi) measurement units.
• Supports Flow engineering units
• 2 Lines 6 digits PV (9.95H x 4.20W mm) 8 Characters
• Square root output indication (√) and Write Protect
• Indication
• Built-in Basic Device Configuration through Internal or
• External Buttons-Range/Engineering Unit/Loop Test /Loop Calibration/Zero /Span Setting

Diagnostics:

• SmartLine transmitters all offer digitally accessible diagnostics which aid in providing advanced warning of possible failure events minimizing unplanned shutdowns, providing lower overall operational costs

System Integration :

• SmartLine communications protocols all meet the most current published standards for Hart
• All ST 700 units are Experion tested to provide the highest level of compatibility assurance

External Two Button Configuration Option :

• Suitable for all electrical and environmental requirements,
• SmartLine offers the ability to configure the transmitter and display, for all basic parameters, via two externally accessible buttons when a display option is selected.
• Zero/span capabilities are also optionally available via two external buttons with or without the selection of the display option.

Internal Two Button Configuration Option :

• The Standard display has two buttons that can be used for Basic configuration such as re ranging
• PV Engineering unit setting, Zero/Span settings, Loop testing and calibration functions.

Hand Held Configuration :

• SmartLine transmitters feature two-way communication and configuration capability between the operator and the transmitter
• This is accomplished via Honeywell's field-rated
• Multiple Communication Configurator (MCT404)
• The MCT404 is capable of field configuring HART Devices and can also be ordered for use in intrinsically safe environments
• All Honeywell transmitters are designed and tested for compliance with the offered communication protocols and are designed to operate with any properly validated hand held configuration device.
