Honeywell Flush Mount Gauge Pressure Transmitters

Product Description

Product Details :

Features :

• Flush mounting design
• Automatic temperature compensation
• Alphanumeric display capabilities External zero, span, & configuration capability
• Polarity insensitive electrical connections
• On-board diagnostic capabilities integral Dual
• Seal design for safety based on ANSI/NFPA 70-202 and ANSI/ISA 12.27.0
• Full compliance to SIL2/3 requirements as a standard. Modular design characteristics

Description :

• The SmartLine family pressure transmitters are designed around a high performance piezo-resistive sensor.
• This one sensor actually integrates multiple sensors linking process pressure measurement with on-board static pressure (DP Models) and temperature compensation measurements.
• This level of performance allows the ST 700 to replace most competitive transmitters available today.

Basic Alphanumeric LCD Display:

• Modular (may be added or removed in the field)
• 0, 90,180, & 270 degree position adjustments
• Configurable and standard (Pa, KPa, MPa, KGcm2, Torr, ATM, inH2O, mH2O, bar, mbar, inH2O, inHG, FTH2O, mmH2O, mm HG, & psi) measurement units
• 2 Lines 16 Characters (4.13H x 1.83W mm)
• Square root output indication

Simple LCD Display Features:

• Modular (may be added or removed in the field)
• Supports HART protocol variant
• 0, 90,180, & 270 degree position adjustments
• Configurable (HART only) and standard (Pa, KPa, MPa, KGcm2, Torr, ATM, inH2O, mH2O, bar, mbar, inH2O, inHG, FTH2O, mmH2O, mm HG, & psi) measurement unit
• Supports Flow engineering units
• 2 Lines 6 digitsPV (9.95H x 4.20W mm) 8 Characters
• Square root output indication and Write protect Indication
• Built in Basic Device Configuration through Internal Buttons –Range/Engineering Unit/Loop Test /Loop Calibration/Zero /Span Setting

External Three Button Configuration Option:

• Suitable for all electrical and environmental requirements, SmartLine offers the ability to configure the transmitter and display via three externally accessible buttons when a display option is selected
• Zero/span capabilities are also optionally available via these buttons with or without the selection of the display option.

Internal Two Button Configuration Option:

• The Simple display has two buttons that can be used for Basic configuration such as re-ranging, PV Engineering unit setting, Zero/Span settings, and Loop testing and calibration functions.

Hand Held Configuration:

• SmartLine transmitters feature two-way communication and configuration capability between the operator and the transmitter.
• This is accomplished via Honeywell’s field-rated Multiple Communication Configurator (MCT404).
• The MCT404is capable of field configuring DE and HART Devices and can also be ordered for use in intrinsically safe environments
• All Honeywell transmitters are designed and tested for compliance with the offered communication protocols and are designed to operate with any properly validated handheld configuration device
